Features: |
| |
1.Carbon steel body, compact, safe |
| |
2.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure, |
| |
which enhance the wind energy utilization and annual output. |
| |
3.Patented permanent magnet ac generator with special stator,effectively reduce torque, |
| |
well match the wind wheel and generator, and ensure the performance of whole system. |
| |
4.Tail adopts mechanical yaw technique, making it survive storm and run safely |
| |
5.With epoxy zinc rich primer and polyurethane anti-corrosion treatment, |
| |
be ultraviolet-proof, acid rain resistant, salt resistant |
| |
6.Controller,inverter can be matched accroding to customers’ specific needs |
| |
|
| |
Parameter |
| |
| |
Model |
NE-3kG |
Rated power |
3kw |
Maximum power |
3.5kw |
Rated voltage |
96/120/220v |
Start-up wind speed |
3m/s |
Rated wind speed |
10m/s |
Survival wind speed |
45m/s |
Top net weight |
205kg |
Wheel diameter |
5.6m |
Number of blades |
3 |
Blades material |
Reinforced glass fiber |
Generator type |
Three phase permanent magnet AC synchronous generator |
Magnet material |
NdFeB |
Generator case |
Carbon steel |
Control system |
Electromagnet/wind wheel yaw |
Speed regulation |
Tail furling |
Working temperature |
-40°C - 80°C |
Design life |
20 y |
Certificates |
CE, ISO14001, ISO 9001,TUV |
|
|
| |
|
|
| |
|
| |
|
| |
|
|
|
| |
|
| |
|
|
